Harrington Hoists Radio Remote Transmitter IC 2802A-SAGA1L8
PRECAUTIONS
·After Operating Series 140-160-180, please press the Stop pushbutton to shut off main power in the Crane & Receiver.
· Stop operating when slow-response occurs due to insufficient Transmitter power, beyond the remote control range, or severe interference.
· Remove the batteries when the equipment won’t be used for a long period.
· Operators must be in good health and have good judgment in regards to safety.
· Remote Control operator must have adequate training and related license to avoid danger. Series 140-160-180 Transmitter is durable and weather-resistant, but care should be taken not to subject it to severe impact or pressure.
· Series 140-160-180 is suitable for use in diverse industrial environments, and adequate operating and maintenance will extend system’s life.
· Check EMS mushroom and the other security functions of Series 140-160-180 system before daily operation.
· Press EMS mushroom when malfunctions or abnormal conditions occur. Operator must be familiar with the following Emergency Procedures before operating.
EMERGENCY PROCEDURES
In case of emergency, please follow the steps below and ask the distributor for service immediately.
·Press the Stop pushbutton.
· Remove the batteries.
· Shut off the main power of the Crane and discontinue the operation.
GENERAL OPERATION
· Turn on the main power switch of the equipment (Crane).
· Install 2 AA batteries in the battery box in the Transmitter. Make sure the polarity is correct.
· Attach Transmitter battery door with screws.
· Press the “Start/R0” Button. Note: LED indicator will flash with red color if proper procedures are not followed.
· Operate Transmitter by pressing each pushbutton.
· After operation, perform the following procedures in sequence:
(1) Press the Stop pushbutton.
(2) Keep the transmitter in a safe place.
(3) Switch main power off to the equipment (Crane).
(4) Remove batteries if not used for a long period of time.
Note: Transmitter has power indicating functions with LED display.
