Tractel Griphoist Controller T4795US
Description
New Tractelift™ Type II climb and descent assist with adjustable pull ing force by user remote. Two remotes are available and depending on the remote chosen the climb assist pulls with a pulling force up to 150 lbs. (75 kg). Tractelift® Type II was developed after listening to Windmill Technicians in the field. Technicians wanted a system that was reliable, easy to use, provided a smooth and more powerful adjustable pulling force while climbing and descending. Tested in the field users agree that the Tractelift™ Type II has achieved these goals and more.
Feature and Benefits:
Reduces worker fatigue while climbing and descending.
User adjustable levels of pulling force while climbing and descend ing.
Smooth running providing controlled starts and stops.
User remote with Illuminated LCD Requires minimal training.
The system consists of five main parts, top pulley (1), bottom pulley (2), pulley belt (3), Drive Unit - 220V - 1PH - 50/60 HZ (4) and remote (5). The top and bottom pulley and belt are permanently mounted to the lad der. The belt is properly tensioned between the two pulleys. The Drive unit is 220V - 1PH - 50/60 HZ available in the following configurations:
a) Fixed drive unit to the lower pulley.
b) Fixed drive unit to the lower pulley with detachable control box.
c) Detachable drive unit to the lower pulley, providing cost/saving benefits by requiring less motors required on site.
Part Numbers:
A - Fixed unit Tractelift™ Type II
TFDC370 - Bottom pulley -gear box - motor assembly - control box
B - Removable Tractelift™ Type II control box
TFDC380 - Bottom pulley - gear box - motor assembly
C - Removable Tractelift™ Type II motor version
TRDC100 - Removable motor complete assembly
