GE Fanuc IC694MDL940F RX3i 交直流电压输出模块
GE Fanuc IC694MDL940F RX3i AC/DC Voltage Output Module, Precision Control Solutions
Rated Voltage:120/240 Volts AC Current Output:2 Amps Output Voltage Range:85 to 264 Volts AC Output Points:8 Relay Type:N.O. Isolation:Yes Operating Temperature:-20"C to +60"C Enclosure Type:IP20 Power Consumption:鈮?5 Watts The GE Fanuc IC694MDL940F is engineered for demanding industrial environments, offering unparalleled precision and reliability in voltage output control. This module is specifically designed for integration into GE PACSystems RX3i platform, ensuring seamless compatibility and enhanced system performance.
With its robust DIN rail connector and wide operating temperature range, this module is suitable for both indoor and outdoor installations, making it versatile for various industrial settings. Its high current output capability ensures efficient power delivery, even under heavy load conditions. The IC694MDL940F features a compact design, allowing for easy installation and space optimization on the control panel. It supports both AC and DC voltage outputs, providing flexibility for diverse automation needs.
Designed with safety in mind, this module includes built-in protection mechanisms against overloads and short circuits, safeguarding the system from potential damage. Its IP20 protection class ensures dust resistance, enhancing durability in harsh industrial environments.
For maintenance and troubleshooting, the IC694MDL940F comes equipped with diagnostic LEDs that indicate module status, facilitating quick identification of operational issues.
This feature minimizes downtime and streamlines maintenance procedures, keeping your system running smoothly and efficiently. The GE Fanuc IC694MDL940F is an advanced AC/DC voltage output module designed for the RX3i series, delivering precise control and reliability in industrial automation systems.
Quality Assurance
(I) Production Process
GE's high standard production process is strictly followed during the production process. The circuit boards of the control modules are assembled using high-precision surface mount technology (SMT) to ensure that the electronic components are installed with micron-level precision. Each soldered joint is strictly inspected, and X-ray inspection equipment is used to check whether there are defects such as false soldering and voids inside the soldered joints, so as to ensure the reliability of the circuit board's electrical connection. The module shell is made of high-strength, fire-resistant, anti-electromagnetic interference engineering plastics. During the injection moulding process, the dimensional accuracy and mechanical strength of the shell are ensured through precise control of mould temperature, pressure and other parameters.
(ii) Quality Inspection
Before the products leave the factory, they have to go through several rounds of strict quality testing. First of all, the function test is carried out to simulate various industrial field environments, and comprehensively test the functions of the control module, such as the accuracy of the input and output signals, the stability of the communication function, and the correctness of the control algorithm. Then the environmental adaptability test, the module will be placed in high temperature, low temperature, high humidity, strong electromagnetic interference and other harsh environments, to test whether its performance is still stable. For example, in the high temperature 85 ℃, relative humidity 85% of the environment for 72 hours of continuous operation, the module indicators can still meet the standard requirements, to ensure its reliable operation in complex industrial environments.
